Alumil SUPREME S700

The SUPREME S700 sliding system is one of our latest premium offerings. It is perfect for projects with strict requirements, embracing the "transparent" architectural trend with large glass surfaces, high thermal insulation, security and modern design. The elegant design and many innovative features make it the ideal choice for projects that need wide openings for increased natural light, exceptional performance and effortless operation.

Schemes

Double lifting sliding sash

Double lifting sliding sash with narrow interlocking profile

Four lifting sliding sashes meeting stile

Four lifting sliding sashes meeting stile with narrow interlocking profile

Corner typology with four lifting sliding sashes

Triple lifting sliding sash

Six lifting sliding sashes with meeting stile

Single lifting sliding pocket sash with fly-screen & shutter

Double lifting sliding pocket sash with meeting stile, with fly-screen & shutter

Single lifting sliding sash with fixed light

Two lifting sliding sashes with fixed light

Single lifting sliding sash with two fixed lights

Double lifting sliding sash with meeting stile & with two fixed lights

Double lifting sliding sash with fly-screen

SASH DEPTH
70mm

MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
91 mm

MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE)
47 mm

GLAZING TYPE
Double - Triple

MAXIMUM GLAZING THICKNESS
from 22 to 50 mm

MECHANISM
Lift & slide mechanism

SEALING METHOD
Perimetrical with EPDM gaskets & tri-fin brushes

MINIMUM THRESHOLD HEIGHT
24 mm

TYPE OF THERMAL INSULATION
Polyamides, ALUMIL Energy bar, Insulation foam,Thermoplastic

Possible Doors

Sliding Doors

Sliding Doors Sliding doors feature a modern design that seamlessly integrates with the interior. These internal bifold doors and sliding systems optimize space usage, creating a visually spacious environment. PROFAL aluminium bifold doors demand minimal maintenance while contributing to a peaceful atmosphere.

Sliding Systems Our sliding bifold doors are designed for smooth operation and durability. They are perfect for creating a seamless connection between your indoor and outdoor areas. Available in various styles, these aluminium bi fold doors add a modern touch to any home.

Lift & Slide Doors For larger openings and superior functionality, our lift & slide bifold doors are the ideal choice. These doors lift off their seals to slide effortlessly, providing excellent insulation and security. They are perfect for making a dramatic visual impact while maintaining energy efficiency.
